ANGLE VALVES, JIS 5K - WITH DNV-GL CLASS CERTIFICATE
CAST STEEL BODY, STAINLESS STEEL TRIM, SCREW DOWN NON RETURN (SDNR)
| DN | Code | Flange OD | PCD | Holes x Dia | Face to Face |
|---|---|---|---|---|---|
| 50 | 750330 | 130 | 105 | 4 | 15 | 110 |
| 65 | 750331 | 155 | 130 | 4 | 15 | 115 |
| 80 | 750332 | 180 | 145 | 4 | 19 | 130 |
| 100 | 750333 | 200 | 165 | 8 | 19 | 150 |
| 125 | 750334 | 235 | 200 | 8 | 19 | 170 |
| 150 | 750335 | 265 | 230 | 8 | 19 | 190 |
| 200 | 750336 | 320 | 280 | 8 | 23 | 220 |
| 250 | 750406SDNR | 385 | 345 | 12 | 23 | 275 |
| 300 | 750407SDNR | 430 | 390 | 12 | 23 | 310 |
| 350 | 750408SDNR | 480 | 435 | 12 | 25 | 360 |
